Description
An electric underfloor heating mat and cable system with pressure-sensitive adhesive for the fastest installation. Features an ultra-thin 1/8? wire that does not raise floor levels.
Key Benefits:
- No Increase in Floor Levels: The thinnest dual fluoropolymer coated heating wire – less than 1/8?
- Durability: Sturdy fiberglass mesh with pressure sensitive adhesive, for the fastest and most secure installation
- Quick Installation: Simply roll out the mat with pre-spaced wire
- Compatible With All Floor Coverings
The Mat System is ideal for installations within regularly shaped areas, where the 20? or 3? wide mats can be quickly rolled out across the floor in parallel runs.
If you intend on using vinyl, carpet, timber, tiles or any other underfloor heating compatible floor finish, the system can (and should, in some cases like for carpet) be embedded within a self-leveling compound to provide a flat and level floor surface to lay over.
Alternatively, the Foil Heater System can be used under laminate, engineered wood, or carpet and offers a completely dry construction that does not require a leveling compound. Or, if the area is irregularly shaped (not a square or rectangular form), or has multiple permanent fixtures in it (like a bathroom, for instance, with toilets, baths, sinks and more), Warmup’s DCM-PRO cable with fixing strips is the more suitable solution.
Specifications:
| Operating voltage | 120V and 240V |
| Width | 20? or 3ft |
| Mat thickness | 1/8? |
| Inner / Outer Insulation | Advanced fluoropolymer |
| Output rating | 14W/sqft |
| Lead Wire | 10ft |
| Approvals | cULus |
Download Specification Sheet
Download Installation Manual
