RainDrain Match Trim Broadwalk for 27 5/8 ” Rough with Height Adjustable Frame

Description

Features

• Consists of: design grate, height adjustable frame, wall installation flange, hair catcher
• Mounting type: wall-mounted, free in the floor
• Easy to clean surface
• Easy adjustment to tile thickness with height adjustable frame 1/4”-3/4”
• Tile thickness: up to 2 3/8”
• Suitable for any type of tile
• Up to 15.85 GPM drainage capacity
• Field of application: new construction, renovation
• Grate removal tool allows easy removal of the pre-fab set
• Type of odor seal: mechanical
• Wall mounting possible
• Tile inlay depth: 1/2”
• Grate material: Stainless Steel 304 (1.4301)
• Suitable for primary and secondary drainage
• Frame width: 2 1/2”

Scope of supply

• drain set
• hair catcher
• mounting material
• grate removal tool
• wall mounting set
• assembly instruction

Technical data

• Scale drawing JPG, 74 KB
• Full coverage drawing JPG, 32 KB

Instructions

• Assembly instruction (Waste) PDF, 2.9 MB

Download Installation Guide
